Toro® - SnowMaster® Service Manual 3-17
Chassis
3
Table of Contents
CHASSIS
8. Install screws into the pulley to secure the pin into
position.
9. Pulley and bearing installation is complete.
Pulley Removal (Cont.)
Replacement (Cont.)
6. Place bearing on shaft. Using a spacer, tap the
bearing in place until the inner race of the bearing is
flush with the shaft.
7. Remove the pinch punch. Insert the new pin.
Figure 50
Figure 51
Figure 52
Figure 53
