Figure28
1.Foamelement2.Paperelement
6.Separatethefoamandpaperelements.
CleaningtheFoamandPaperElements
FoamElement:
1.Washthefoamelementinliquidsoapandwarmwater.
Whentheelementisclean,rinseitthoroughly.
2.Drytheelementbysqueezingitinacleancloth.Do
notoiltheelement.
Important:Replacethefoamelementifitistorn
orworn.
3.Installthefoamelementonacleanpaperelement.
PaperElement:
1.Tapthepaperelementonasolidatsurfaceandblow
itoutfromtheinsidewithcompressedairtoremove
dustanddirt.
2.Inspecttheelementfortears,anoilylm,anddamage
totherubberseal.
Important:Donotcleanthepaperelementwith
liquids,suchassolvents,gasoline,orkerosene.
Replacethepaperelementifitisdamagedor
cannotbecleanedthoroughly.
3.Cleantheinsideoftheaircleanercoverofalldirt,dust,
anddebris.
InstallingtheFoamandPaperElements
Important:Topreventenginedamage,alwaysoperate
theenginewiththecompletefoamandpaperaircleaner
assemblyinstalled.
1.Installthefoamlterontothepaperlter(Figure28).
2.Installthefoamandpaperlterontotheaircleaner
housing.
3.Installtheaircleanercoverandtightenthetwoknobs
(Figure27).
ServicingtheEngineOil
OilType:Detergentoil(APIserviceSF,SG,SH,SJ,orhigher)
CrankcaseCapacity:1.0l(34ounces)whenyoudonotchange
thelter;1.05l(36ounces)whenyouchangethelter.
Viscosity:Seethetablebelow.
Figure29
CheckingtheOilLevel
1.Parkthemachineonalevelsurface.
2.Disengagethebladecontrol(PTO).
3.Stoptheengine,waitforallmovingpartstostop,and
removethekeybeforeleavingtheoperatingposition.
4.Cleanaroundtheoildipstick(Figure30)sothatdirt
cannotfallintothellholeanddamagetheengine.
G017863
2
Figure30
1.Oildipstick/llhole
2.Aircleaner
5.Unscrewtheoildipstickandwipetheendclean.
6.Screwtheoildipstickfullyontothellhole.
7.Unscrewthedipstickagainandlookattheend.Ifthe
oillevelislow,slowlypouronlyenoughoilintothell
holetoraisetheleveltotheFullmarkonthedipstick.
25
