G014895 2
1.
2.
3
Figure 11
FilI opening 3. FueI
Base of filler neck, DO 4. Empty space for fueI
NOT FILL PAST HERE expansion.
,
Important: Do Not overfill fuel tank. Fill
the fuel tank to the bottom of the filler neck.
The empty space in the tank allows the fuel to
expand. Overfilling may result in fuel leakage
or damage to the engine or emission system.
Install the fuel tank cap securely and tighten until it
"clicks". Wipe up any gasoline that may have spilled.
Checking the Engine Oil Level
Before you start the engine and use the machine, check
the oil level in the engine crankcase; refer to ChecMng
the Oil Level in the Engine Maintenance section.
Starting the Engine
1. Sit down on the seat and move the motion controls
outward to the park position.
2. Disengage the blades by moving the blade control
switch to Off (Figure 12)
2
1. Control panel
1
Figure 12
2. Blade control switch--Off
position
,
Pull up on the Choke control before starting a cold
engine (Figure 13).
Note: A warm or hot engine may not require
cho_ng.
6
,dllbm5
G014902
Figure 13
1. Control panel 4. Continuous variable
setting
2. Throttle 5. Stow
3. Fast 6. Choke control
,
Turn the igicition key to Start to energize the starter.
When the engine starts, release the key (Figure 14).
Important: Do not engage the starter for more
than 10 seconds at a time. If the engine fails
to start, allow a 60 second cool-down period
between attempts. Failure to follow these
instructions can damage the starter motor.
19
