Lubrication
GreasingtheBearings
Machineswith42-inch,50-inch,or
54-inchMowerDecksOnly
ServiceInterval:Every25hours—Greasealllubrication
points(42-inchor50-inchdecksonly).
GreaseType:No.2lithiumgrease
1.Parkthemachineonalevelsurfaceanddisengagethe
blade-controlswitch.
2.Movethemotion-controlleversoutwardtothePARK
position,shutofftheengine,removethekey,and
waitforallmovingpartstostopbeforeleavingthe
operatingposition.
3.Cleanthegreasettings(Figure32andFigure33)with
arag.
Note:Makesuretoscrapeanypaintoffthefrontof
thetting(s).
g032432
Figure32
1.Frontcastertire
decal106-8717
Figure33
Locatedontheseat-panunderside
1.Readtheinstructions
beforeservicingor
performingmaintenance.
3.Greaseevery25operating
hours.
2.Checkthetirepressure
every25operatinghours.
4.Engine
4.Connectagreaseguntoeachtting(Figure32and
Figure33).
5.Pumpgreaseintothettingsuntilgreasebeginsto
oozeoutofthebearings.
EngineMaintenance
EngineSafety
Shutofftheenginebeforecheckingtheoiloraddingoilto
thecrankcase.
ServicingtheAirCleaner
ServiceInterval:Beforeeachuseordaily
Note:Servicetheaircleanermorefrequently(everyfew
hours)ifoperatingconditionsareextremelydustyorsandy.
RemovingtheElements
1.Parkthemachineonalevelsurface.
2.Disengagetheblade-controlswitch(PTO).
3.Engagetheparkingbrake.
4.Shutofftheengineandremovethekey.
5.Cleanaroundtheair-cleanercovertopreventdirtfrom
gettingintotheengineandcausingdamage.
6.Liftthecoverandrotatetheair-cleanerassemblyout
oftheengine(Figure34).
g027800
g027800
g027801
g027801
Figure34
