6 - 16 TimeCutter™ Z Service Manual
CHASSIS
6
Replace the brake switch and install wiring.
Install the brake handle on the brake shaft.
Position the rear brake shaft on the chassis with
the upper brake rod through the hole in the lever
and secure with a washer and cotter pin.
0702-0620
0702-0619
0702-0616
