Toro TRX-16 Original Instructions

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
Boom(soldseparately)
1
1
Chain(soldseparately)
1
Installtheboomandchain.
2
Nopartsrequired
–
Checktheuidlevels.
3
Nopartsrequired
–
Chargethebattery.
1
InstallingtheBoomandChain
Partsneededforthisprocedure:
1
Boom(soldseparately)
1
Chain(soldseparately)
Procedure
Important:Thereareseveralboomandchainsize
congurationsavailable.RefertoyouAuthorizedService
Dealertoobtaintheappropriateboomandchainto
meetyourrequirements.
1.Stoptheengineandremovethekey.
2.Removethebolt,2saddlewashers,andnutsecuring
thespoilsaugerandremovetheauger(Figure4).
Note:Savethefastenersforfutureuse.
Figure4
1.Spoilsauger
6.Adjustingbolt
2.Boom7.Jamnut
3.Bolts8.Armonthedrivehead
4.Doublewasher9.Drivesprocket
5.Nuts
3.Removethe2bolts,nuts,anddoublewashersfromthe
sidesoftheboom(Figure4).
4.Loosentheadjustingboltandjamnut(Figure4).
5.Slidetheboomoverthearmonthedrivehead.
6.Installthe2bolts,nuts,anddoublewashersremovedin
step3throughtheboomandarm,butdonottighten
them.
7.Ifthechainisnotconnected,connectthelinksby
pressingorhammeringtheclevispinsuppliedwiththe
chainthroughthelinks.
Important:Toavoidbendingthechainlinks,
placeblocksunderandbetweenthelinkswhen
hammeringtheclevispinthrough.
8.Securetheclevispinwiththecotterpinsuppliedwith
thechain.
12
