•Iftheside-dischargechuteisonthemachine,removeit
andinstalltheside-dischargedeector;refertoRemoving
theSide-dischargeChute(page14).
•Ifthegrassbagisonthemachine,removeit;referto
RemovingtheGrassBag(page14).
•Iftherear-dischargeplugisnotinstalled,gripitbythe
handle,raisethereardeector,andinsertitintothe
rear-dischargechuteuntilthelatchlocksintoplace;refer
toFigure20.
G019812
Figure20
1.Rear-dischargeplug
2.Reardeector
WARNING
Ensurethattherear-dischargeplugisinplace
beforeyourecycletheclippings.Neverengagethe
bladeswithouteithertherear-dischargeplugorthe
grassbaginstalled.
BaggingtheClippings
Usethegrassbagwhenyouwanttocollectgrassandleaf
clippingsfromthelawn.
WARNING
Aworngrassbagcouldallowsmallstonesandother
similardebristobethrowntowardtheoperatoror
bystandersandresultinseriouspersonalinjuryor
death.
Checkthegrassbagfrequently.Ifitisdamaged,
installanewTororeplacementbag.
Iftheside-dischargechuteisonthemachine,removeit
andinstalltheside-dischargedeectorbeforebaggingthe
clippings;refertoRemovingtheSide-dischargeChute(page
14).
WARNING
Thebladesaresharp;contactingthebladescan
resultinseriouspersonalinjury.
Stoptheengineandwaitforallmovingpartstostop
beforeleavingtheoperatingposition.
InstallingtheGrassBag
1.Raiseandholdupthereardeector(Figure21).
1
G019798
2
Figure21
1.Bagrod
2.Reardeector
2.Removetherear-dischargeplugbypullingdownonthe
latchwithyourthumbandpullingtheplugoutfrom
themachine(
Figure20).
3.Installthebagrodintothenotchesatthebaseofthe
handle,androckthebagbackandforthtoensurethat
13
