2.Removethebeltcover(Figure7)byremovingthe4
boltsthatholdittothemachinehousing.
3.Checkthebeltsforanycracks,frayededges,burn
marks,oranyotherdamage.
4.Replacealldamagedbelts.
5.Ifyoureplacetheblade-drivebelt,youmustadjustit.
Referto
ServicingtheBlade-driveSystem(page19).
6.Installthebeltcoverwiththe4boltsthatyouremoved
instep2.
EmptyingtheFuelTankand
CleaningtheFilter
ServiceInterval:Every50hours—Checkthefuelhoseand
replaceitifnecessary.
Every100hours—Cleanthefueltanklter.
Yearlyorbeforestorage—Emptythefueltankbefore
repairsasdirectororbeforestorage.
Note:Thefueltanklter(screen)elementislocatedinside
thefueltankattheoutlet.Thislterisapartofthefueltank
andcannotberemoved.
1.Stoptheengineandwaitforittocooldown.
Important:Draingasolinefromacoldengine
only.
2.Disconnectthewirefromthesparkplug.
3.Closethefuelshut-offvalve.
4.Disconnectthefuellinebylooseningthetubeclampat
thecarburetor.
5.Openthefuelshut-offvalveanddrainthegasoline
completelyfromthetankandfuellineintoanapproved
fuelcontainer.
6.Removethefueltankfromthemachine.
7.Pourasmallamountoffuelinthefueltank,move
thefuelaroundinthetank,andpouritoutintoan
approvedfuelcontainer.
8.Installthefueltankandthefuelline.
ChangingtheFuelFilter
ServiceInterval:Every100hours
1.Stoptheengineandwaitforallmovingpartstostop.
2.Disconnectthewirefromthesparkplug.
3.Closethefuelshut-offvalve(Figure29).
g019650
1
g019924
1
2
Figure29
1.Fuellter2.Fuelshut-offvalve
4.Removethefuellter(Figure29)fromthefuellineby
looseningthetubeclampssurroundingthefuellter.
5.Installanewfuellterinthefuellineusingthetube
clampsthatyouremovedinstep4.
ServicingtheBlade-drive
System
ServiceInterval:Aftertherst5hours
Every50hours—Removedebrisfromunderthebelt
cover.
Every50hours—Servicetheblade-drivesystem.
1.Loosenthe2screwsonthebelt-cover-accesspaneland
removethepanel(
Figure30).
g019641
1
2
3
4
5
6
7
8
Figure30
1.Belt-tensionspring5.Blade-drivebelt
2.Adjustingbolt6.Wall
3.Gap
7.Beltcover
4.Adjustingnut8.Belt-cover-accesspanel
19
