ChangingtheOilFilter
ServiceInterval:Every100hours
1.Runtheenginetowarmtheoil.
WARNING
Oilmaybehotaftertheenginehasbeenrun,
andcontactwithhotoilcancausesevere
personalinjury.
Avoidcontactingthehotengineoilwhenyou
drainit.
2.Stoptheengineandwaitforallmovingpartstostop.
3.Disconnectthewirefromthesparkplug.
4.Draintheengineoil;referto
ChangingtheEngineOil
(page17).
5.Placearagundertheoilltertocatchanyoilthatmay
leakoutasyouremovethelter.
6.Removetheoillter(
Figure26).
g019650
1
Figure26
1.Oillter
7.Useyourngertocoatthegasketonthenewlter
withoil(Figure27).
Figure27
1.Gasket
8.Installthenewlteruntilthegasketcontactsthelter
base,thenhandtightenthelteranadditional2/3turn.
9.FillthecrankcasetotheFulllineonthedipstickwith
freshoil;referto3FillingtheCrankcasewithOil(page
7).
10.Connectthewiretothesparkplug.
11.Runtheengineforabout3minutes.
12.Stoptheengine,waitforallmovingpartstostop,and
checkforoilleakagearoundthelter.
13.Addoiltocompensatefortheoilintheoillter;refer
to
CheckingtheEngineOilLevel(page9)
14.Recycletheusedoillteraccordingtolocalcodes.
ServicingtheSparkPlug
ServiceInterval:Every100hours
UseanNGKBPR5ESsparkplugorequivalent.
1.Stoptheengineandwaitforallmovingpartstostop.
2.Disconnectthewirefromthesparkplug.
3.Cleanaroundthesparkplug.
4.Removethesparkplugfromthecylinderhead.
Important:Replaceacracked,fouled,ordirty
sparkplug.Donotcleantheelectrodesbecause
gritenteringthecylindercandamagetheengine.
5.Setthegapontheplugto0.030in.(0.76mm);refer
toFigure28.
Figure28
1.Center-electrodeinsulator3.Airgap(nottoscale)
2.Sideelectrode
6.Installthesparkplugandthegasketseal.
7.Torquetheplugto17ft-lb(23N-m).
8.Connectthewiretothesparkplug.
CheckingtheConditionofthe
Belts
ServiceInterval:Every50hours
1.Stoptheengineandwaitforallmovingpartstostop.
