Toro TurfMaster 22200 - Product Overview; Component Identification; Control Bar and Throttle Operation

ProductOverview
1
2
3
4
5
6
7
8
9
10
11
12
13
14
G019803
15
Figure7
1.Sparkplug(underbrush
guard)
9.Grassbag
2.Airlter
10.Rearcutting-heightlever
3.Oilll/dipstick11.Fuelshut-offvalve
4.Throttlelever
12.Oillter
5.Fuel-tankcap13.Beltcover
6.Reardeector
14.Frontcutting-heightlever
7.Handle15.Belt-cover-accesspanel
8.Controlbar
g019644
1
2
3
4
Figure8
1.Grassbag3.Side-dischargechute
2.Rear-dischargeplug
4.Side-dischargedeector
Controls
g019652
1 2
3
4
Figure9
Throttle(Throttlelevernotshownforthesakeofclarity)
1.Choke3.Slow
2.Fast
4.Stop
1
2
G019669
Figure10
Controlbar
1.Handle
2.Controlbar
8
