Setup
1
InstallingtheHandle
NoPartsRequired
Procedure
WARNING
Foldingorunfoldingthehandleimproperlycan
damagethecables,causinganunsafeoperating
condition.
•Donotdamagethecableswhenfoldingor
unfoldingthehandle.
•Ifacableisdamaged,contactanAuthorized
ServiceDealer.
1.Removethe2boltsfromthemachineframeinthe
locationshowninFigure3.
G019802
1
2
Figure3
1.Bolt(2)
2.Nutonhandlesupport
bracket(2)
2.Rotatethehandlerearwardtotheoperatingposition.
3.Securethehandletothemachinewiththeboltsthat
youremovedinstep
1
4.Tightenthefastenersthatsupportthehandleonboth
sidesofthemachineasshowninFigure4.
G021273
2
1
3
Figure4
1.Cabletie3.Bolt(4)
2.Nutonhandlesupport
bracket(2)
5.Useacabletietosecurethecablestothelowerhandle
inthelocationshowninFigure4.
6.Securethecabletieonthehandleandtrimoffthe
excessmaterialfromthetie.
2
AdjustingtheHandleHeight
NoPartsRequired
Procedure
1.Standintheoperatingpositiontodeterminethemost
comfortablehandleheight.
2.Removethehandleboltandinsertitin1ofthe3holes
locatedatthebottomofthehandlebracket(Figure5).
6
