Rev. A
Workman HDX/HDX--D Page 10 -- 15 Front Wheel Drive (4WD)
Front Differential Disassembly
1. Make sure that the oil is drained from the differential
assembly.
2. Remove the four (4) flange head screws from the in-
put cover (Fig. 11). Remove the cover.
3. Remove the pinion shaft from housing by pulling it
out of the gear case by hand (Fig. 12).
4. Inspect the inner pinion bushing in the gear case
(Fig. 13). If the bushing is excessively worn, the gear
case must be replaced. The bushing is not serviced sep-
arately.
1. Input cover 2. Pinion shaft
Figure 11
2
1
1. Pinion shaft 2. Gear case
Figure 12
2
1
1. Pinion bushing 2. Gear case
Figure 13
2
1
Front Wheel
Drive (4WD)
