Toshiba B-EP4DL-GH20-QM-R User Manual

18
(Unit: mm)
Item Media
Label
Tag/Receipt
Receipt
Batch mode
Peel-off mode
With black mark
No black mark
(A) Label/Receipt pitch 10.0 - 999.9 13.0 - 67.0 10.0 – 999.9 ---
(B) Label/Receipt length 7.0 - 997.0 10.0 - 60.0 7.0 - 997.0 ---
(C) Backing paper width 50.0 – 115.0 ---
(D) Media width 48.0 – 113.0 50.0 – 115.0
(E) Gap/black mark length 3.0 - 7.0 ---
(F) Vertical gap 1.0 – 7.0 ---
(G) Effective print width 104.0
(H) Effective print length 7.0 - 995.0 8.0 - 58.0 7.0 - 995.0 ---
(I) Top and bottom margin Min. 1.0 ---
Outer roll diameter Φ68 (max.)
Roll direction Outside
NOTE:
Do not use the media other than the above to ensure print quality and print head life.
