1. PRODUCT OVERVIEW ENGLISH VERSION EO1-33062
1.5 Appearance
E1- 3
1.5 Appearance
1.5.1 Dimensions
1.5.2 Front View
1.5.3 Rear View
The names of the parts or units introduced in this section are used in the
following chapters.
Dimensions in mm (inches)
Power Jack
Power Switch
Rear Media Guide
Parallel Interface
Connector (Centronics)
USB Interface
Connecto
r
Serial Interface
Connector
(RS-232C)
213 (8.4)
314
(
12.4
)
188
(7.4)
Top Cover
Cover Open Lever
FEED/PAUSE
Button
Media Outle
t
Indicator Lam
p
Ribbon Access Cover
Label Roll Capacity
View Window
