8 Appendix
158 e-STUDIO2007/2307/2507 Specifications
e-STUDIO2007/2307/2507 Specifications
These specifications vary depending on the copying conditions and the environment.
Specifications and appearance are subject to change without notice in the interest of product improvement.
Model name DP-2007/2307/2507
Type Desktop type
Original glass Fixed
Printing (copying) system Indirect electrophotographic method
Developing system 2-component magnetic brush developing
Fusing method Two halogen lamp
Photosensor type OPC
Original scanning system Flat surface scanning system
(When the Reversing Automatic Document Feeder is installed: Fixed scanning
system by feeding the original)
Original scanning sensor Linear CMOS sensor
Scanning light source LED
Resolution Writing 2400 dpi x 600 dpi (Smoothing process)
Scanning 600 dpi x 600 dpi
Acceptable originals Sheets and books
Acceptable original size Original glass: Max. A3 or LD
Reversing Automatic Document Feeder: Max. A3 or LD
Acceptable paper size Drawer A3, A4, A4-R, A5-R, B4, B5, B5-R, FOLIO, LD, LG, LT, LT-R, ST-R, COMP,
13"LG, 8.5"SQ, 8K, 16K, 16K-R
Bypass A3, A4, A4-R, A5-R, B4, B5, B5-R, FOLIO, LD, LG, LT, LT-R, ST-R, COMP,
13"LG, 8.5"SQ, 8K, 16K, 16K-R, COM10, Monarch, DL
Acceptable paper weight Drawer
64 - 80 g/m
2
(17 - 20 lb. Bond)
Bypass
64 - 80 g/m
2
(17 - 20 lb. Bond) : for continuous feed
52 - 63 g/m
2
(14 lb. Bond - 16 lb. Bond), 81 - 163 g/m
2
(21 lb. Bond - 90 lb.
Index) : for single feed
Warm-up time Approx. 20 seconds
First copy time (A4 or LT portrait) A4: Approx. 7.0 seconds
LT: Approx. 7.1 seconds
Continuous copy speed See P.159 “Continuous copying speed”
Multiple copying Up to 999 copies
Excluded image width Copy Leading edge: 3.0±2.0 mm (0.12"±0.08")
Trailing edge: 2.0±2.0 mm (0.08"±0.08")
Both edges: 2.0±2.0 mm (0.08"±0.08")
Printer Leading edge: 5.0±3.0 mm (0.20"±0.12")
Trailing edge: 5.0±3.0 mm (0.20"±0.12")
Both edges: 5.0±3.0 mm (0.20"±0.12")
Reproduction ratio Actual size 100±0.5%
Zoom 25 - 400% (in 1% increments)
Storage capacity Max. 100 sheets or until the memory is full (TOSHIBA’s own chart)
Paper supply Drawer
250 sheets (80 g/m
2
, 20 lb. Bond)
Bypass
100 sheets (80 g/m
2
, 20 lb. Bond)
Loading capacity for the receiving tray
Approx. 100 sheets (80 g/m
2
, 20 lb. Bond)
Toner density adjustment Magnetic auto-toner system
Exposure control Automatic plus manual selection from 9 exposure steps
Memory 512MB
USB interface USB2.0 (Hi-Speed)
Environment (for normal use) Temperature: 10 º - 30 ºC, Humidity: 20 - 85% (No condensation)
Power requirements and power consumption
(including optional equipments)
AC 220 - 240 V±10%, 8 A (50 - 60 Hz): 1.5 kW or less
AC 120 V±10%, 12 A (60 Hz): 1.5 kW or less
Dimensions (equipment only) 575 mm (22.6") (W) x 565 mm (22.2") (D) x 402 mm (15.8") (H)
Weight (including equipment and drum) Approx. 27kg (59.5 lb.)
Space occupied (equipment only) 933 mm (36.7") (W) x 565 mm (22.2") (D)
