1 TROUBLESHOOTING FOR THE HARDWARE
Cleaning the Main Chargers and LED Print Heads 65
Cleaning the Main Chargers and LED Print Heads
When it is time for cleaning the inside of the equipment, the message "Time for cleaning. Open the front cover and follow
the guidance." is displayed. In this case, clean the main chargers (or, the main chargers and LED print heads) following
the guidance displayed on the touch panel.
Even if the message is not displayed, perform cleaning when the copied image has unevenness and/or white or color
streaks in the horizontal direction ( P.72).
1
Open the front cover of the equipment.
2
Pull out the cleaner until the mark appears and return
it. Repeat this 3 times for each of the 4 colors.
The cleaner cannot be removed by design. Pulling it out forcibly
may cause malfunction.
When only the main chargers need to be cleaned, steps 3 to 12 are
unnecessary. Proceed to step 13.
3
Put your fingers in the waste toner box front grooves
and take it out toward you pushing down the top
latch.
4
Place the waste toner box on a large sheet so as not
to dirty the floor.
Do not place the waste toner box with its collecting port face
down.
The waste toner may spill out from the box's collecting port.
To Next Page
