–14–
EN
• Fix the unit in a horizontal position.
When unit is fixed to slant, it may cause overflow of drainage.
• Install the unit within the dimension according to the figure below.
• Use level gauge or vinyl hose to confirm whether the unit is fix horizontally.
Remove the part for transportation
Be sure to remove the transportation part before operating the unit.
Front view
0 to 5 mm
Set the drain pipe connecting port
side within 5 mm lower than
opposite side.
Side view
± 5 mm
Set the front and air back sides are
within 5 mm with each other.
27-EN 28-EN
+00EH99897401-3_00Ta.book Page 14 Wednesday, May 11, 2016 3:36 PM
