–7–
3 System control of Hot Water Module
System able to be combined
The hot water module is connectable to only SMMS-i (Super Modular Multi system).
The system does not work when it connect to the MiNi-SMMS, SMMS (5,6 HP) and SHRM-i cannot be connected.
The Fresh Air Intake type and Air to Air Heat Exchanger with DX Coil cannot be connected with the same refrigerant system.
* When hot water module units and standard indoor units are not operated simultaneously.
▼ Capacity code of hot water module
• For the hot water module, the capacity code is decided at each model. (Table 1)
Table 1
The capacity code of the hot water module is different from the capacity code of the standard indoor unit.
Compared with the capacity code of the outdoor unit, the total value of capacity codes of the connectable indoor units (including hot water module) differs based on the height difference between the indoor units (including hot water module).
• When the height difference between the indoor units (including hot water module) is 15 m or less: Up to 115 % (including hot water module) of the capacity code (Equivalent to HP) of the outdoor unit (Equivalent to HP) of the outdoor unit.
• When the height difference between the indoor units (including hot water module) is over 15 m: Up to 105 % (including hot water module) of the capacity code.
No. Item
SMMS-i with
Hot Water Module connection
SMMS-i without
Hot Water Module connection
1 System capacity 48 HP 48 HP
2 No. of outdoor units connected 44
3 Indoor connection capacity
Max.
115 %
(including Hot Water Module)
135 %
Min.
65 %
(excluding Hot Water Module)
50 %
4 Hot Water Module connection capacity per refrigerant system Max. 2 units and 50 % or less -
5
Height
difference
Height between outdoor and indoor units (including hot water module)
H1
H2 > 3 m
Upper outdoor units 50 m
See Figure 1
50 m
Lower outdoor units 30 m 30 m
H2 ≤ 3 m
Upper outdoor units 70 m 70 m
Lower outdoor units 40 m 40 m
Height between indoor units (including hot water module)
H2, H4, H5
Indoor - Indoor
H2
Upper outdoor units 3 m (*40)
40 m
Lower outdoor units 10 m (*40)
Indoor - Hot water module
H5
Upper outdoor units 3 m (*40) -
Lower outdoor units 10 m (*40) -
Hot water module -
Hot water module
H4
Upper outdoor units 3 m -
Lower outdoor units 3 m -
Hot Water Module - Hot Water Module Max. 3 m -
Hot water module model
Capacity code
Equivalent to HP Equivalent to capacity
MMW-AP0271LQ-TR 2.5 7.1
MMW-AP0561LQ-TR 5 14
13-EN 14-EN
