INTERFACE MANUAL
Correspondence table
between [U07] set value (example) and program file name
Signal name in DIN command
Program file name
(EXTRNSEL. SYS)
4
3
2
1
"PROG1" 0 0 0 0
"PROG2" 0 0 0 1
"PROG3" 0 0 1 0
"PROG4" 0 0 1 1
"PROG5" 0 1 0 0
"PROG6" 0 1 0 1
"PROG7" 0 1 1 0
"PROG8" 0 1 1 1
"PROG9" 1 0 0 0
"PROG10" 1 0 0 1
"PROG11" 1 0 1 0
"PROG12" 1 0 1 1
"PROG13" 1 1 0 0
"PROG14" 1 1 0 1
"PROG15" 1 1 1 0
"PROG16" 1 1 1 1
When bits underlined = 12, two (2) external digital input signals 1 and 2 are used,
and the number of program files selected is four (4) from "PROG1" ~ "PROG4".
To register the program file name to the program number, use the EXTRNSEL. SYS
file.
Copyright (C) 2001 by TOSHIBA MACHINE CO., LTD.
All rights reserved.
External select file "EXTRNSEL. SYS"
*** [ 00 - 0F ] *****
= "PROG00"
= "PROG01"
= "PROG02"
= "PROG03"
STE 71367
– 43 –
