Toshiba TMC7 Series User Manual

SPECIFICATIONS
TMC7 Series
Page 8
710-02887-00A
EMC Emission
Equipment class (EMC) .............................................................................................................................................................. Class A
Conducted radio frequency emission ............................................................................................. 0.15 MHz to 0.5 MHz : <90 dB (µV)
0.5 MHz to 5 MHz : <76 dB (µV)
5 MHz to 30 MHz : 80-60 dB (µV)
Radiated radio frequency emission ............................................................................................. 30 MHz to 230 MHz : <30 dB (µV/m)
230 MHz to 1000 MHz : <37 dB (µV/m)
This product has been designed for Class A equipment. Use of the product in domestic environments may cause radio interference, in
which case the user may be required to employ additional mitigation methods.
EMC Immunity
Electrostatic discharge ........................................................................................................ 4 kV contact discharge, 8 kV air discharge
Radio frequency electromagnetic field .......................................................................................... 0.15 MHz to 1000 MHz: 140 dB (µV)
Fast transients 5/50 ns (Main & control circuits) ............................................................................................................... 2 kV / 5.0 kHz
Surges 1.2/50 µs – 8/20 ms (Main & control circuits) ........................................................................ 2 kV line to earth, 1 kV line to line
Voltage dip and short time interruption .............................................................................................. 5000 ms (at 0% nominal voltage)
Short Circuit
Rated short-circuit current TMC7-007 to TMC7-037 ....................................................................................................................... 5 kA
Rated short-circuit current TMC7-045 to TMC7-110 ..................................................................................................................... 10 kA
Heat Dissipation
During Start ................................................................................................................................................................. 3 watts / Ampere
During Run ................................................................................................................................................................................ < 4 watts
Standards Approvals
C9 .................................................................................................................................................................................. IEC 60947-4-2
CE .................................................................................................................................................................................... IEC 60947-4-2

Toshiba TMC7 Series Specifications

General

Brand	Toshiba
Model	TMC7 Series
Category	Controller
Language	English
