E6581440
- 10 -
4.2. Drive I/O Objects
4.2.1. Binary Input Object Instance
Binary input objects allow to monitor the inverter actual terminal ON/OFF status.
These objects are read only. If it is necessary to read inverter terminal output status via
BACnet® network, Binary input object can be used to. Binary input #0 is FL labeled
terminal monitor. Whatever function is set to the FL terminal by parameter f132, it
indicate a terminal level that inverter would try to output.
Instance ID Object Name Description
Active /
Inactive
Acce
ss
Binary input #0 RO 1 ACT Inverter FL terminal monitor (f132 **) ON / OFF R
Binary input #1 RO 2 ACT Inverter OUT1 terminal monitor (f130 **) ON / OFF R
Binary input #2 RO 3 ACT Inverter OUT2 terminal monitor (f131 **) ON / OFF R
Binary input #3 * RO 4 ACT Inverter R2 terminal monitor (f138 **) ON / OFF R
Binary input #4 * RO 5 ACT Inverter OUT5 terminal monitor (f136 **) ON / OFF R
Binary input #5 * RO 6 ACT Inverter OUT6 terminal monitor (f137 **) ON / OFF R
Binary input #6 DI 1 ACT Inverter F terminal monitor ON / OFF R
Binary input #7 DI 2 ACT Inverter R terminal monitor ON / OFF R
Binary input #9 DI 4 ACT Inverter RES terminal monitor ON / OFF R
Binary input #10 DI 5 ACT Inverter S1 terminal monitor ON / OFF R
Binary input #11 DI 6 ACT Inverter S2 terminal monitor ON / OFF R
Binary input #12 DI 7 ACT Inverter S3 terminal monitor ON / OFF R
Binary input #13 DI 8 ACT Inverter RR/S4 terminal monitor ON / OFF R
Binary input #14 * DI 9 ACT Inverter LI5 terminal monitor ON / OFF R
Binary input #15 * DI 10 ACT Inverter LI6 terminal monitor ON / OFF R
Binary input #16 * DI 11 ACT Inverter LI7 terminal monitor ON / OFF R
Binary input #17 * DI 12 ACT Inverter LI8 terminal monitor ON / OFF R
* These are enabled with ETB004Z(Expansion IO card option).
** These parameters affect the function of terminals.
R=Read-only, W=Writable, C=Commandable.
