E6581440
- 13 -
4.2.4. Analog Input Object Instance
The analog input objects allow to monitor inverter analog input terminal level.
These objects only read inverter parameters those are prepared as read only monitor
parameters(from fe35 to fe39).
These objects present-value unit is “%” unit, and present-value=100.0% mean analog
input terminals are a full range input level.
Instance ID Object Name Description Access
Analog Input #0 ANALOG INPUT 1 RR/S4 analog input level. (fe35) R
Analog Input #1 ANALOG INPUT 2 VI/II analog input level. (fe36) R
Analog Input #2 ANALOG INPUT 3 RX analog input level. (fe37) R
Analog Input #3 ANALOG INPUT 4 AI1 analog input level. (fe38) R
Analog Input #4 ANALOG INPUT 5 AI2 analog input level. (fe39) R
Analog Input #3,#4 : These are enabled with ETB004Z(Expansion IO card option).
R=Read-only, W=Writable, C=Commandable.
4.2.5. Analog Output Object Instance
The analog output objects allow to control inverter analog(AM,FM,…) output levels, and
also can be used priority-array and relinquish-default property.
These objects only write to inverter parameters(
fa51-fa54). It is necessary to set
meter function selection parameters(see below table) to 31.
Instance ID Object Name Description Access
Analog output #0 AO1 COMMAND Set fmsl to 31, in order to use inverter FM terminal. W
Analog output #1 AO2 COMMAND Set amsl to 31, in order to use inverter AM terminal. W
Analog output #2 AO3 COMMAND Set f672 to 31, in order to use MON1 terminal on
the expansion IO card option.
W
Analog output #3 AO4 COMMAND Set f674 to 31, in order to use MON2 terminal or
pulse output terminal on the expansion IO card option.
W
Analog output #2,#3 : These are enabled with ETB004Z(Expansion IO card option).
R=Read-only, W=Writable, C=Commandable.
