E6582051
- 44 -
6.5.12.
fd01
(Inverter operating status 1 (real time)) (VF-S15/MB1)
bit Function 0 1 Note
0 Failure FL No output Under in progress -
1 Failure Not tripped Tripped
Trip status includes
rtry
and
the trip retention status are also
regarded as tripped statuses.
2 Alarm No alarm Alarm issued -
3 Under voltage (
moff
) Normal Under voltage -
4
Motor selection (1 or 2)
(THR 2 selection)
Motor 1 (THR1) Motor 2 (THR2)
THR1:
pt
= setting value,
vl
,
vlv
,
vb
,
thr
THR2:
pt
=
0
,
f170
,
f171
,
f172
,
f173
5 PID control off
PID control
permitted
PID control
prohibits
-
6
Acceleration/deceleratio
n pattern selection (1 or
2)
Acceleration/dec
eleration pattern
1 (AD1)
Acceleration/dec
eleration pattern
2 (AD2)
AD1:
acc
,
dec
AD2:
f500
,
f501
7 DC braking OFF
Forced DC
braking
-
8 Jog run OFF Jog run -
9 Forward / reverse run Forward run Reverse run -
10 Run/stop Stop Run -
11 Coast stop (ST = OFF) ST=ON ST=OFF -
12 Emergency stop
No emergency
stop status
Emergency
stop status
-
13 Standby ST=ON Start-up process Standby
Standby: Initialization
completed, not failure stop
status, not alarm stop status
(
moff
,
ll
forced stop),
ST=ON, and RUN=ON
14 Standby Start-up process Standby
Standby: Initialization completed,
not failure stop status and not
alarm stop status (
moff
,
ll
forced stop)
15 (Undefined) - - -
Note: The bit described "Undefined" is unstable. Don't use the bit for the judgment.
