E6582051
- 47 -
6.5.16.
fe35
,
fe36
,
fe37
(Monitoring of the analog input VIA, VIB, VIC) (VF-S15/MB1)
VIA terminal board monitor: "Communication Number
fe35
"
VIB terminal board monitor: "Communication Number
fe36
"
VIC terminal board monitor: "Communication Number
fe37
"
These monitors can also be used as A/D converters irrespective of the drive's control.
VIA / VIC terminal board monitor is capable of reading the data from external devices in a range of 0.01 to
100.00% (unsigned data: 0x0000 to 0x2710).
VIB terminal board monitor is capable of reading the data from external devices in a range of -100.00 to
100.00% (signed data: 0xD8F0 to 0x2710).
If analog input mode is selected with the frequency setting mode selection parameter, however, keep in
mid that any data entered via an analog terminal is regarded as a frequency command.
6.5.17. fe35, fe36, fe37 (Monitoring of the analog input RR, RX, II) (VF-AS3)
fe35
: RR terminal board monitor
fe36
: RX terminal board monitor
fe37
: II terminal board monitor
These monitors can also be used as A/D converters irrespective of the drive's control.
RR / II terminal board monitor is capable of reading the data from external devices in a range of 0.01 to
100.00% (unsigned data: 0x0000 to 0x2710).
RX terminal board monitor is capable of reading the data from external devices in a range of -100.00 to
100.00% (signed data: 0xD8F0 to 0x2710).
If analog input mode is selected with the frequency setting mode selection parameter, however, keep in
mind that any data entered via an analog terminal is regarded as a frequency command.
6.5.18.
fe14
(Cumulative run time)
The operated cumulative time is read by the hexadecimal number.
For example, when cumulative operation time is 18 hours, 0x12 (18 hours) is read.
0x12 (Hex.) = 18 (Dec., hour)
6.5.19.
fe40
(FM output monitor),
fe41
(AM output monitor) (Only for the VF-AS3)
The output value of FM terminal or AM terminal are read are read.
The value range is set to 0 to 10000 (0x2710).
