Toto SN970M - Parts Names

* Use these devices for flushing water during
power outage.(Page 50)
Toilet lid and toilet seat underside
Left side of top unit
Right side of top unit
Water filter drain valve
Deodorizer vent
Deodorizing filter
Water drain plug
Cover
Side cover
Side cover (right side interior)
Gasket
Toilet seat cushions
Battery box
Manual flush pull cord
Seat switch(Built-in here)
Body sensor B
Body sensor A
Side cover
Water filter
(Internal parts of the
water supply valve)
Water supply hose
Bowl unit
Warm air dryer door
Heated seat
Wand door
Wand
Toilet lid
Toilet lid cushion
Power plug
Water shutoff valve
Tain unit
Remote
control
receiver
Main display
POWER LED SEAT LED
WATER LEDENERGY SAVER LED
Washlet control panel
POWER ON/OFF button
FRONT ON/OFF button
"FULL FLUSH" button
REAR ON/OFF button
* Use in situations such as when the remote control
batteries have discharged.
Model name, part no., etc.
12
13
Introduction
Parts names
