Reference
Specications
Item Description
Rated power supply AC120 V, 60 Hz
Rated power consumption 406 W
Type Hot-water system
Power cord length 3.6ft (1.1m)
Bowl unit
features
Flush volume Full 1.28 gal (4.8L), Light 0.9gal (3.4L)
Water supply system Built-in tank reservoir
Flush type “Cyclone” (Siphon type)
Bowl style Elongated
Washlet
function
Washlet
Spray
volume
Rear cleansing
Approx. 0.08 to 0.16 gal/min. (Approx. 0.29 to 0.60 L/min.)
<at 29 PSI (0.20 MPa) water pressure>
Soft rear
cleansing
Approx. 0.08 to 0.15 gal/min. (Approx. 0.29 to 0.55 L/min.)
<at 29 PSI (0.20 MPa) water pressure>
Front cleansing
Approx. 0.07 to 0.15 gal/min.(Approx. 0.27 to 0.55 L/min.)
<at 29 PSI (0.20 MPa) water pressure>
Water temperature
Temperature adjustable range: OFF, about 86 to 104°F (about 30 to 40°C)
Heater capacity 250 W
Tank capacity 0.20 gal (0.78 L)
Safety device
Temperature fuse, overheat shutoff switch (bimetal automatic return
type), anti-idling oat switch
Dryer
Warm air temperature
*
Temperature adjustable range: About 104 to 138°F (About 40 to 54°C)
Airow volume 9.54 ft
3
/min (0.27 m
3
/min)
Heater capacity 350W
Safety device Temperature fuse
Heated
seat
Surface temperature
Temperature adjustable range: OFF, about 82 to 95°F (about 28 to 36°C)
<In auto energy-saver: About 79°F (About 26°C)>
Heater capacity 50W
Safety device Temperature fuse
Deodorizer
Method 0
2
Deodorizer
Airow volume Approx. 5.65 ft
3
/min. (Approx. 0.16 m
3
/min.)
Power consumption Approx. 5.8 W
Water supply pressure
Minimum required water pressure: 7.25 PSI (0.05MPa) <Dynamic>
Maximum water pressure: 108.75 PSI (0.75MPa) <Static>
Supply water temperature 0 to 95°F (0 to 35°C)
Working ambient temperature 0 to 104°F (0 to 40°C)
Dimensions W1332 ft, D2379 ft, H1995 ft (W406 mm, D725 mm, H608 mm)
Weight
Approx. 101 lb (Approx. 45.8 kg)
<Top Unit 17.42 lb (7.9 kg), Bowl Unit 83.56 lb (37.9 kg)>
Temperature around the warm air outlet measured by TOTO.
*
Limited Warranty
1. TOTO warranties its washlet series ("Washlet") to be free from defects in materials and workmanship during normal use
when properly installed and serviced, for a period of one (1) year from date of purchase. This limited warranty is
extended only to the ORIGINAL PURCHASER of the Washlet and is not transferable to any third party, including but not
limited to any subsequent purchaser or owner of the Washlet. This warranty applies only to TOTO Washlet is purchased
and installed in North, Central and South America.
2. TOTO's obligations under this warranty are limited to repair, replacement or other appropriate adjustment, at TOTO's
option, of the Washlet or parts found to be defective in normal use, provided that such Washlet was properly installed,
used and serviced in accordance with instructions.
TOTO reserves the right to make such inspections as may be necessary in order to determine the cause of the defect.
TOTO will not charge for labor or parts in connection with warranty repairs or replacements. TOTO is not responsible for
the cost of removal, return and/or reinstallation of the Washlet.
3.This warranty does not apply to the following items:
a) Damage or loss sustained in a natural calamity such as fire, earthquake, flood, thunder, electrical storm, etc.
b) Damage or loss resulting from any accident, unreasonable use, misuse, abuse, negligence, or improper care,
cleaning, or maintenance of the Washlet.
c) Damage or loss resulting from sediments or foreign matter contained in a water system.
d) Damage or loss resulting from improper installation or from installation of the Washlet in a harsh and/or hazardous
environment, or improper removal, repair or modification of the Washlet. This includes locations where the water
pressure is above local codes or standards. (NOTE : Washlet model codes allow a maximum of 80 PSI. Check local
codes or standards for requirements).
e) Damage or loss resulting from electrical surges or lightning strikes or other acts which are not the fault of TOTO or
which the Washlet is not specified to tolerate.
f) Damage or loss resulting from normal and customary wear and tear, such as gloss reduction, scratching or fading
over time due to use, cleaning practices or water or atmospheric conditions.
4. If the Danger Label which has been placed over the seams on the back of the Product s top unit is broken or otherwise
not intact, this limited warranty is void.
5. In order for this limited warranty to be valid, proof of purchase is required. TOTO encourages warranty registration upon
purchase to create a record of Product ownership at http://www.totousa.com. Product registration is completely
voluntary and failure to register will not diminish your limited warranty rights.
6. If the Product is used commercially or is installed outside of North, Central or South America, TOTO warrants the
Product to be free from defects in materials and workmanship during normal use for one (1) year from the date of
installation of the Product, and all other terms of this warranty shall be applicable except the duration of the warranty.
7. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHER RIGHTS WHICH VARY FROM
STATE TO STATE, PROVINCE TO PROVINCE OR COUNTRY TO COUNTRY.
8. To obtain warranty repair service under this warranty, you must take the Product or deliver it prepaid to a TOTO service
facility together with proof of purchase (original sales receipt) and a letter stating the problem, or contact a TOTO
distributor or products service contractor, or write directly to TOTO U.S.A., INC., 1155 Southern Road, Morrow, GA
30260 (888) 295 8134 or (678) 466-1300, if outside the U.S.A. If, because of the size of the Product or nature of the
defect, the Product cannot be returned to TOTO, receipt by TOTO of written notice of the defect together with proof of
purchase (original sales receipt) shall constitute delivery. In such case, TOTO may choose to repair the Product at the
purchase'r s location or pay to transport the Product to a service facility.
WARNING! TOTO shall not be responsible or liable for any failure of, or damage to, this Product caused by either
chloramines in the treatment of public water supply or cleaners containing chlorine (calcium hypochlorite).
NOTE: The use of a high concentrate chlorine or chlorine related product's can seriously damage the fittings. This
damage can cause leakage and serious property damage.
THIS WRITTEN WARRANTY IS THE ONLY WARRANTY MADE BY TOTO. REPAIR, REPLACEMENT OR OTHER
APPROPRIATE ADJUSTMENT AS PROVIDED UNDER
THIS WARRANTY SHALL BE THE EXCLUSIVE REMEDY
AVAILABLE TO THE ORIGINAL PURCHASER. TOTO SHALL NOT BE RESPONSIBLE FOR LOSS OF THE
PRODUCT OR FOR OTHER INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OR EXPENSES INCURRED
BY THE ORIGINAL PURCHASER, OR FOR LABOR OR OTHER COSTS DUE TO INSTALLATION OR REMOVAL, OR
COSTS OF REPAIRS BY OTHERS, OR FOR ANY OTHER EXPENSE NOT SPECIFICALLY STATED ABOVE. IN NO
EVENT WILL TOTO'S RESPONSIBILITY EXCEED THE PURCHASE PRICE OF THE PRODUCT. EXCEPT TO THE
EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTIES, INCLUDING THAT OF
MERCHANTABILITY OR FITNESS FOR USE OR FOR A PARTICULAR PURPOSE, ARE EXPRESSLY DISCLAIMED.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, OR THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION AND
EXCLUSION MAY NOT APPLY TO YOU.
