Fasten Lift To Cabinet – cont.
3. Once the lift is placed in the cabinet and aligned with the center of the cabinet, fasten the lift to the back wall of
the cabinet. Install 4 nylon spacers (#3) between the back mounting arms on the lift and the wall of the cabinet and
insert a ST6x45 Wood Screw (#5) through each back mounting arm and nylon spacer, securing the lift to the back
wall of the cabinet.
4. Fasten lift to floor of the cabinet, using the mounting holes in the base of the lift.
5. Once the lift is installed, reinstall the TV Lift plate that was removed in step 1.
