Assembling and Installing 2800/3900 SRV PRO 360-Degree Swivel TV Lift
Fasten Lift To Cabinet
The 2800/3900 SRV PRO 360-Degree Swivel TV Lift has 8 mounting points (4 on the back of the lift and 6 on the
floor). Use the 4 rear mounting points and the 6 floor mounting points to mount the lift in your cabinet.
Parts Required:
- Screwdriver or cordless-drill
- Hex wrench
Instructions:
1. The 2800/3900 SRV PRO 360-Degree Swivel TV Lift ships with the 360-Degree Swivel TV Lift plate already
installed. For easier installation, remove the 4 bolts securing the TV Lift plate to the top of the lift and remove the
TV Lift plate from the lift.
2. Place lift in cabinet and align in center of cabinet so that the center of the lift is lined up with the midpoint of the
TV opening in the cabinet.
