Toyota Corolla E12-A - Carpet Modification and Bracket Installation

Corolla (E12-A + E12-D) TOYOTA GENUINE AUDIO
Corolla (RHD) - 23
05-04
12. Attach the spacers and the tapes
to the base bracket .
: Screw (M5x10) (2x)
: Spacer with nut (2x)
: Tape(2x)
1
17
15
13
1
17
Fig. 41
13
15
17
17
13
1
17
1
13.
a) Cut the carpet as shown.
b) Strip off the insulation at the reverse
side of the carpet.
17
Fig. 42
Rib for insertion of the weather strip
80mm
269mm
120mm
Cut the carpet
35mm
235mm
145mm
17
Console box
