Chapter 1
Get to Know About Your Router
1. 2. 2. Back Panel
The router’s back panel shows the connection ports, buttons and antennas (view from
left to right). Refer to the following for detailed instructions.
Item Description
Internet Port For connecting to a DSL/Cable modem, or an Ethernet jack.
L
AN Ports (1, 2,
3, 4)
For connecting your PC or other Ethernet network devices to the router.
Power Port
For connecting the router to a power socket via the provided power
adapter.
Power On/Off
Button
Press this button to power on or off the router.
Antennas Used for wireless operation and data transmit.
