TP-Link Archer C5400 - Specifications

109
Specifications
Hardware
Ethernet Ports
Four 10/100/1000Mbps LAN Ports
One 10/100/1000Mbps WAN Port
USB Port
One USB 3.0 Port
One USB 2.0 Port
Button WPS Button, Reset Button, Wireless On/Off Button, LED On/Off Button, Power On/Off Button
External Power Supply 12V/5A
Dimensions (W x D x H) 230mm×230mm×43mm
Antenna Four dual band Fixed antennas & Four single band Fixed antennas
Wireless
Wireless Standards IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n/ac 2.4GHz
Frequency
2.4GHz, 5GHz Band 1&4
Signal Rate 2166Mbps at 5GHz, 1000Mbps at 2.4GHz
Transmit Power
CE: <20dBm(2.4GHz), <23dBm(5150GHz to 5350GHz), <30dBm(5470GHz to 5725GHz)
FCC: <30dBm
Reception Sensitivity
5GHz: 11a 6Mbps: -91dBm; 11a 54Mbps: -73dBm; 11n HT20: -69dBm; 11n HT40: -67dBm;
11ac HT20: -66dBm; 11ac HT40: -61dBm; 11ac HT80: -58dBm
2.4GHz: 11g 54Mbps: -76dBm; 11n HT20: -73dBm; 11n HT40: -71dBm
Wireless Function Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
Wireless Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions
Software
WAN Type Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)/Bigpond
DHCP Server, DHCP Client List, Address Reservation
Quality of Service WMM, Bandwidth Control
Port Forwarding Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS DynDns, NO-IP
VPN PPTP, Open VPN
Access Control Parental Control, Local Management Control, Host list, Access Schedule, Rule Management
Firewall Security DoS, SPI Firewall, IP Address Filter/Domain Filter, IP and MAC Address Binding
Protocols Supports IPv4 and IPv6
USB Sharing Supports Samba(Storage)/FTP Server/Media Server/Printer Server
Management Access Control, Local Management, Remote Management
Guest Network 2.4GHz guest network x 1, 5GHz guest network x 1
Environment
Operating Temperature 0℃~40℃ (32℉ ~104℉)
Storage Temperature -40℃~70℃ (-40℉ ~158℉)
Operating Humidity 10%~90% non-condensing
Storage Humidity 5%~90% non-condensing
