TP-Link Archer C7 AC1750 User Manual

Archer C7
AC1750 Wireless Dual Band Gigabit Router
3. Delete all or disable all entries if there are any entries already.
4. Click the
Add New... button.
1) Enter the MAC address 00-0A-EB-B0-00-0B/00-0A-EB-00-07-5F in the MAC Address
field.
2) Enter wireless station A/B in the Description field.
3) Select Enabled in the Status drop-down list.
4) Click the Save button.
5) Click the Back button.
The filtering rules that configured should be similar to the following list:
4.6.5 Wireless Advanced
Choose menu “Wireless 2.4GHz
→
Wireless Advanced”, you can configure the advanced
settings of your wireless network.
Figure 4-28 Wireless Advanced
 Transmit Power - Here you can specify the transmit power of router. You can select High,
Middle or Low which you would like. High is the default setting and is recommended.
 Beacon Interval - Enter a value between 20-1000 milliseconds for Beacon Interval here.
The beacons are the packets sent by the router to synchronize a wireless network. Beacon
Interval value determines the time interval of the beacons. The default value is 100.
- 44 -

TP-Link Archer C7 AC1750 Specifications

General

Ethernet Ports	4 x Gigabit LAN, 1 x Gigabit WAN
Memory	128MB RAM, 16MB Flash
Wireless Standard	IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz
Frequency Band	2.4 GHz, 5 GHz
Wi-Fi Speed	450Mbps at 2.4GHz, 1300Mbps at 5GHz
USB Ports	1 x USB 2.0
Antennas	3 external detachable antennas
Security	64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Dimensions	9.6 x 6.4 x 1.3 in (243 x 160.6 x 32.5 mm)
Weight	0.93 lbs (0.42 kg)
