Figure 5-26 Add a Rule
Scheduler Association
This zone will display different contents based on your selection of association mode in
Settings.
1. Associated with SSID
Figure 5-27 Scheduler Association_Associated with SSID
SSID Name:
Displays the SSID of the standalone AP.
Band:
Displays the frequency band which the wireless network operates at.
Profile Name:
Select a profile name from the drop-down list. Profile name is configured in
Scheduler Profile Configuration.
Action:
Select Radio On/Off
to turn on/off the wireless network during the time
interval set for the profile.
26
