TP-Link CPE Series Installation Guide

11
• Point-to-Point
Point-to-Point application is used to build a transparent bridge
below is an example for this application.
2.
and hotspot applications. Refer to the section
corresponding to your networking needs.
1. Log in to PharOS
2. Go to the Quick Setup page
3. Operation Mode
 Select 'Access Point'.
 Click 'Next'.
4. LAN Settings: Click 'Next'.
5. Wireless AP Settings
 SSID: customize the name for the network as you like.
 Security: select 'WPA-PSK/WPA2-PSK'.
 PSK Password: create the password for the network as you like.
 Distance Setting: enter the distance between the Access Point and
the Client. It is recommended to round the number up to the
nearest integer.
 Select the MAXtream option if the Access Point and the Client
both are Pharos outdoor CPEs. (Refer to 'Q4' in 'FAQ' for details abo
ut
MAXtream)
 Click 'Next'.
6. Finsh: Click 'Finish'.
IP camera
Access Point
LAN: 192.168.0.254
Client
LAN: 192.168.0.2
Computer

TP-Link CPE Series Specifications

General

Model	CPE Series
Wireless Standards	IEEE 802.11a/n
Frequency	5 GHz
Antenna	Directional
Wireless Security	WPA/WPA2, WPA-PSK/WPA2-PSK
Operating Modes	Access Point, Client, Repeater, Bridge
Power Supply	Passive PoE (Power over Ethernet)
Operating Temperature	-30°C to 70°C
Storage Temperature	-40°C~70°C (-40℉~158℉)
Humidity	10%~90% non-condensing
Enclosure	Weatherproof design
Chipset	Atheros
RAM	Varies by Model
Flash Memory	Varies by Model
Ethernet Ports	1
