TP-Link CPE Series Installation Guide

16
HARDWARE FEATURES
Dimensions
CPE520/CPE220: 275.83*79*60.3mm
CPE510/CPE210: 224.34*79*60.3mm
Interface
LAN0: 10/100Mbps Ethernet Port(PoE IN)
LAN1: 10/100Mbps Ethernet Port
GND: Grounding Terminal for Lightning Protection
RESET: Button to restore the device to Factory Default
Power Supply
24V Passive PoE Adapter Included
ESD Protection
1
15kV
Lightning Protection
1
Up to 6kV
Operating
Temperature
-30
℃
~ 70
℃
(-22
℉
~158
℉
)
Operating Humidity 10% ~ 90%
CE, FCC, RoHS, IPX5
WIRELESS FEATURES
Models CPE210 CPE220 CPE510 CPE520
Antenna Gain 9dBi 12dBi 13dBi 16dBi
Horizontal Beamwidth/
Elevation Beamwidth
2
70°/ 45 45°/ 30° 45°/ 30° 50°/ 20°
Operating
Frequency
3
2.4-
2.4835GHz
2.4-
2.4835GHz
802.11 Standards 11b/g/n 11b/g/n 11a/n 11a/n
CE:5.5-5.725GHz
FCC:5.15-5.25GHz;
5.745-5.85GHz
CE:5.5-5.725GHz
FCC:5.15-5.25GHz;
5.745-5.85GHz
This is fixed point-to-point device not point-to-multipoint device.

TP-Link CPE Series Specifications

General

Model	CPE Series
Wireless Standards	IEEE 802.11a/n
Frequency	5 GHz
Antenna	Directional
Wireless Security	WPA/WPA2, WPA-PSK/WPA2-PSK
Operating Modes	Access Point, Client, Repeater, Bridge
Power Supply	Passive PoE (Power over Ethernet)
Operating Temperature	-30°C to 70°C
Storage Temperature	-40°C~70°C (-40℉~158℉)
Humidity	10%~90% non-condensing
Enclosure	Weatherproof design
Chipset	Atheros
RAM	Varies by Model
Flash Memory	Varies by Model
Ethernet Ports	1
