After the power is on, ecoNET300 requires
app. 1 minute in order to load the
operational system. Then, the module begins
to work and indicates its condition with LED
indicators. In a connection between
ecoNET300 module with a regulator is active,
a “ connection with controller” indicator
lights up. New functions for managing
ecoNET300 module are added to the main
menu.
MENU → Information → ecoNET WiFi
MENU → Information → ecoNET Ethernet
MENU → Main settings → WiFi
In case of connection with LAN wire network,
a ecoNET Ethernet tab will be available in
regulator menu from which the IP number,
mask and gate can be read out and
ecoNET24 server connection condition can be
checked. It is required to save the displayed
IP number (e.g. IP:10.1.2.237). This
number in a form of: http://10.1.2.237 is
entered into the address field from the level
of LAN network. A website to operate the
regulator menu will be activated.
It is necessary to enter network parameters
in General settings menu of the control
panel in order to make a wireless connection
via Wi-Fi.
To do this, select:
MENU → general settings → WiFi (WiFi
settings)
Select SSID in Network Settings. It is a
name of the local wireless network which has
to be the same for all devices working in this
network (SSID can be, e.g.: myWiFi).
In case of connection with a chosen Access
Point via wireless network, user has to know
the settings of Wi-Fi network which the
module will be connected to: network name
(SSID), protection type, access password.
The ecoNET300 requires active DHCP server
of Access Point (e.g. router) because
manual IP assignment for ecoNET300
internet module is not supported. More
information can be obtained from router
configuration software or network
administrator.
