JetStream Gigabit L2 Managed Switch
19Conguration
Chapter 5 Configuration
5.1 Configure the Switch via GUI
1. To access the GUI of the switch, open a web browser and type the default management address
http://192.168.0.1 in the address field of the browser, then press the Enter key.
Figure 5-1 Web Browser
Note:
To log on to the GUI of the switch, the IP address of your PC should be set in the same subnet
addresses of the switch. The IP address is 192.168.0.x ("x" is any number from 2 to 254),
Subnet Mask is 255.255.255.0.
2. Enter admin for the default User Name and Password, both in lower case letters. Then click the
Login button or press the Enter key.
Figure 5-2 Login
3. After a successful login, the main page will appear as the following figure, and you can configure
the function by clicking the setup menu on the left side of the screen.
