TP-Link Pharos CPE220 User Manual

05
• Orientation
Install the CPE devices with the front facing the intended signal receiving
devices. You can orient the devices with the assistance of Google Maps,
GPS and some landmarks according to the horizontal beamwidth listed
below.
Models CPE210 CPE220 CPE510
Horizontal Beamwidth 65° 60° 45°
A
shenzhen
B
Line of Sight
Horizontal
Beamwidth

TP-Link Pharos CPE220 Specifications

General

Wireless Standards	IEEE 802.11b/g/n
Frequency	2.4GHz
Antenna Gain	12dBi
Memory	64MB DDR2 RAM, 8MB Flash
Button	Reset Button
Voltage range	16-27VDC
Wireless Speeds	300Mbps
Wireless Security	WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Transmit Power	Up to 27 dBm
Ethernet Ports	1 x 10/100Mbps Ethernet Port
Power Supply	24V Passive PoE (Pairs 4, 5+;7, 8-)
Operating Temperature	-30°C to 70°C
Processor	Qualcomm Atheros
Interface	1 Grounding Terminal
Power Consumption	10.5W max
Operating Modes	AP / Client / AP Router / AP Client Router (WISP)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Weight	0.6 kg (1.32 lb)
