TP-Link TC7650 User Manual

3
Chapter 1
Get to Know Your Modem
1. 1. Product Overview
TP-LINK’s cable modem is designed for delivering ultra-high speed data through coax
used in HFC (Hybrid Fiber-Coaxial) networks. It’s an incredibly robust device allowing
users to access internet and share it with a Gigabit Ethernet port.
This modem complies with DOCSIS 3.0, supports channel bonding of up to 24
downstream channels and 8 upstream channels, combined with Enhanced security of
AES encryption, IPv4 and IPv6 dual stack, which makes it future-proof.
1. 2. Product Appearance
1. 2. 1. Front Panel
The modem’s LEDs are located on the front panel (view from top to bottom). They
indicate the device’s working status. For details, please refer to LEDs Explanation.
LEDs Explanation:
LED Status
Indication
Power
Off The power is off.
On The power is on.

TP-Link TC7650 Specifications

General

Modem speed	1440000 Kbit/s
Antenna type	Internal
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	-30 - 70 %
DC input voltage	12 V
Power requirements	12VDC 1A
Power LED	Yes
Cabling technology	10/100
Ethernet LAN (RJ-45) ports	1
Certification	FCC, UL Cablelabs RoHS
Housing material	Plastic
Cables included	LAN (RJ-45)
Compatible operating systems	Windows 8/Windows 7/ Windows Vista™, Service Pack 1 or later/ Windows®XP, Service Pack 2 or later/ Mac®10.4 or later (Ethernet Connection Only) UNIX®Linux®
