TP-Link TC7650 User Manual

8
Chapter 2
Quick Start
2
1
Coaxial cablePower adapter
Internet
3
Ethernet cable
Cable
Power
LAN
Reset
4. Wait until the Internet LED turns solid. The modem has synchronized with your
ISP’s server.
Note:
1. If the Internet LED does not turn solid after about 1 minute, call your ISP’s customer service.
2. The product should be connected to cable distribution system that grounded (earthed) in accordance with ANSI/
NFPA 70, the National Electrical Code (NEC), in particular Section 820.93 - Grounding of Outer Conductive Shield of
a Coaxial Cable.
2. 3. Activate the Modem
1. Get your Internet service account information and the modem’s Information Card
ready.
Serial Number
MAC Address
2. Make sure your computer is set to dynamically obtain an IP address. If not, refer to
Appendix: Troubleshooting > T5 for instructions.
3. Launch a web browser, and visit any website. You will be automatically redirected to
your ISP’s self-activation page.
4. Follow the on-screen instructions to activate the modem, and wait for about 10
minutes till the LEDs
turn solid.
If you have any problem activating the modem, call your ISP’s customer service.

TP-Link TC7650 Specifications

General

Modem speed	1440000 Kbit/s
Antenna type	Internal
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	-30 - 70 %
DC input voltage	12 V
Power requirements	12VDC 1A
Power LED	Yes
Cabling technology	10/100
Ethernet LAN (RJ-45) ports	1
Certification	FCC, UL Cablelabs RoHS
Housing material	Plastic
Cables included	LAN (RJ-45)
Compatible operating systems	Windows 8/Windows 7/ Windows Vista™, Service Pack 1 or later/ Windows®XP, Service Pack 2 or later/ Mac®10.4 or later (Ethernet Connection Only) UNIX®Linux®
