To set Motion Eye Care
[Depending upon model]
SETTINGS PICTURE Picture Mode
Picture Option
• Motion Eye Care Automatically adjusts
brightness and reduces image blur based on
image data to reduce eyestrain.
Important Information
(For LX530S, LX540S series)
You can download the SuperSign Software and TV
manual from LG Electronics website.
Visit www.lgecommercial.com/supersign for
Software & www.lgecommercial.com/supersigntv
for TV manual.
Server : SuperSign W_Server_Lite_vx.x.x_Setup.zip
SuperSign C_v.X.X.X_Setup.zip
SuperSign W_Editor_vx.x.x_Setup.zip
Editor : SuperSign W_Editor_vx.x.x_Setup.zip
Manual : SuperSign W_Server_Lite_vx.x.x_Manual.
zip SuperSign W_Editor_vx.x.x_Manual.
zip SuperSign C_vX.X.X_Manual.zip
Specifications
Product specifications may be changed without
prior notice due to upgrade of product functions.
Television System
ATSC, NTSC-M, 64 & 256 QAM
Program Coverage
VHF 2-13, UHF 14-69, DTV 2-69, CATV 1-135,
CADTV 1-135
External Antenna Impedance
75 Ω
Environment Condition
• Operating Temperature
0 °C to 40 °C (32 °F to 104 °F)
• Operating Humidity
Less than 80 %
• Storage Temperature
-20 °C to 60 °C (-4 °F to 140 °F)
• Storage Humidity
Less than 85 %
RGB(PC), HDMI (PC) Supported Mode
(Use HDMI IN 1 for PC mode)
Resolution
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
640 x 350 31.46 70.09
720 x 400 31.46 70.08
640 x 480 31.46 59.94
800 x 600 37.87 60.31
1024 x 768 48.36 60.00
1360 x 768 47.71 60.01
1152 x 864 54.34 60.05
1280 x 1024
(For FHD)
63.98 60.02
1920 x 1080
(For FHD)
67.50 60.00
* FHD
42LX330C, 49LX341C, 55LX341C, 60LX341C,
65LX341C, 42LX530S, 49LX540S, 55LX540S,
60LX540S, 65LX540S, 43LX310C, 49LX310C
HDMI (DTV) Supported Mode
Resolution
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
720 x 480p
31.47 59.94
31.50 60.00
1280 x 720p
44.96 59.94
45.00 60.00
1920 x 1080i
33.72 59.94
33.75 60.00
1920 x 1080p
26.97 23.97
27.00 24.00
33.71 29.97
33.75 30.00
67.43 59.94
67.50 60.00
Component Port Connecting Information
Component ports on the TV Y P
B
P
R
Video output ports on DVD player
Y P
B
P
R
Y B-Y R-Y
Y Cb Cr
Y Pb Pr
