TP-Link TD-W8951ND User Manual

TD-W8951ND
150Mbps Wireless N ADSL2+ Modem Router
Rev: 3.0.1
1910010606

TP-Link TD-W8951ND Specifications

General

VPN support	PPTP, L2TP, IPSec
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Input current	0.85 A
Rack mounting	No
Frequency range	2.4 - 2.4835 GHz
Operating temperature (T-T)	32 - 104 °F
WLAN data transfer rates supported	150 Mbit/s
DHCP client	-
Supported network protocols	PPPoE, PPPoA, IPoA
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Security algorithms	128-bit WEP, 64-bit WEP, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-PSK
Certification	CE, FCC, RoHS
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
DSL specification	ANSI T1.413 Issue 2, ITU-T G.992.1, ITU-T G.992.2, ITU-T G.994.1, ITU-T G.995.1, ITU-T G.996.1, ITU-T G.997.1, ITU-T K.2.1, ITU-T G.992.3, ITU-T G.992.4, ITU-T G.992.5
Antenna gain level (max)	3 dBi
Product color	White
Wi-Fi standards	802.11b, 802.11g
Top Wi-Fi standard	802.11g

Weight and Dimensions

Depth	120 mm
Width	174 mm
Height	29 mm
Weight	- g

Summary

COPYRIGHT & TRADEMARKS

FCC STATEMENT

Details FCC compliance for digital devices, covering emission limits and user responsibilities regarding interference.

FCC RF Radiation Exposure Statement

National restrictions

Lists country-specific restrictions for device usage, including noted limitations for France and Norway.

Industry Canada Statement

Korea Warning Statements

Provides warning statements specific to the use of wireless devices in Korea.

NCC Notice

Includes regulatory notices from Taiwan's National Communications Commission (NCC).

DECLARATION OF CONFORMITY

Package Contents

Introduction

Product Overview

Provides a general description of the TD-W8951ND modem router and its main functions and capabilities.

Main Features

Highlights the key features and specifications of the modem router, such as ports, technologies, and performance.

Hardware Installation

The Front Panel

Explains the front panel LEDs and their status indicators for power, ADSL, Internet, WLAN, and LAN connectivity.

The Back Panel

Details the physical ports and buttons on the back panel, including POWER, ON/OFF, WPS, and RESET functions.

Connecting the Modem Router

Provides step-by-step instructions for connecting the modem router to the ADSL line, computer, and power source.

Quick Installation Guide

Configure PC

Guides users through setting up their computer's IP address to establish network connectivity with the router.

Login

Explains how to access the router's web-based configuration interface using its IP address and default credentials.

Software Configuration

Status

Allows users to view current device information, system logs, and network traffic statistics for monitoring.

Interface Setup

Covers configuration for Internet, LAN, and Wireless interfaces to establish network connectivity and settings.

Advanced Setup

Details advanced network settings including Firewall, Routing, NAT, QoS, VLAN, and ADSL configurations.

Access Management

Provides tools for managing access control, filtering, SNMP, UPnP, DDNS, and CWMP functions.

Maintenance

Covers essential device upkeep tasks like administration, time zone settings, firmware upgrades, and diagnostics.

Help

Offers access to help information and guides for configuring various functions of the router.

Appendix A: Specifications

Appendix B: Troubleshooting

Restore Factory Default Settings

Explains the procedure to reset the router to its original factory default settings for troubleshooting.

Cannot Access Web Configuration Page

Provides steps to troubleshoot issues preventing access to the router's web interface for configuration.

Appendix C: Technical Support
