TP-Link TD-W8980 Application Guide


Overview
FTP (File Transfer Protocol) server feature allows you to share a USB storage device that’s connected to the modem router, to
users in the local or public network.
Typical Topology
Here in this guide, we take the configuration procedures of TD-W8968 for example.
Before setting up the FTP Server, make sure you have the following devices:
9 Computer with Windows 2000/ XP/ Vista/ 7/ 8/ Mac OS X/ Linux
9 Storage devices with USB 2.0/3.0 port
)
Note:
(1) USB Storage Device stands for FTP Server in this topology. Some USB storage devices may require using the external power.
(2) Local PC here means the PC that is in the same subnet with the FTP Server (TD-W8968). Local PC can access the FTP Server
by LAN (Local Area Network), which is called LAN Access.
(3) Remote PC here means the PC that is not in the same subnet with the FTP Sever. Remote PC needs to go through the Internet
if needed to access the FTP server, which is called WAN Access.
-1-


TP-Link TD-W8980 Specifications

General

VPN support	PPTP, L2TP
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Input current	1.5 A
Rack mounting	No
Frequency band	2.4 & 5 GHz
USB ports quantity	2
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	4
DHCP client	-
Supported network protocols	ATM/PPP
Antennas quantity	5
Antenna connector type	RP-SMA
Security algorithms	128-bit AES, 128-bit WEP, 256-bit AES, 3DES, 64-bit WEP, DES, WPA, WPA-PSK, WPA2, WPA2-PSK
Authentication method	MD5, SHA-1
Certification	CE, FCC, RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45), Phone (RJ-11)
Output voltage	12 V

Weight and Dimensions

Depth	160.6 mm
Width	243 mm
Height	32.5 mm
Weight	- g
