TP-Link TL-R470T User Manual

-12-
Figure 3-7
Note:
If the above screen (Figure 3-7) does not prompt, it means that your web-browser may be set to a
proxy. Choose Tools menu→Internet Options→Connections→LAN Settings, in the screen that
appears, cancel the Using Proxy checkbox, and click OK to finish it.
After a successful login, the “Quick Setup” screen will pop up as the Figure 3-8 shown. If it does not
prompt, you can click the Quick Setup on the left of the main menu. Then click <Next>.
Figure 3-8 Quick Setup
Select the total number of WAN ports you prefer to use as the Figure 3-9 shown. Then click <Next> to
load the WAN Port screen.

TP-Link TL-R470T Specifications

General

Protocols	TCP/IP, PPPoE, DHCP, ICMP, NAT
DHCP	DHCP Server, DHCP Client
Firewall Security	IP and MAC Address Binding
Ports	5 x RJ45 ports
VPN Support	PPTP VPN, L2TP VPN, IPSec VPN
Management	Web-based GUI
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
