-42-
MAC Clone:
It’s only available for WAN port. Click the <Restore Factory MAC>
button to restore the MAC address to the factory default value or
click the <Clone Current PC’s MAC> button to clone the MAC
address of the PC you are currently using to configure the Router.
Then click <Save> to apply.
Note:
To avoid a conflict of MAC address on the LAN, it’s not allowed to set the MAC address of the Router’s
LAN port to the MAC address of the current management PC.
4.3.4 Switch
Some basic switch port management functions are provided by TL-R470T+, which facilitates you to
monitor the traffic and manage the network effectively.
4.3.4.1 Statistics
Statistics screen displays the detailed traffic information of each port, which allows you to monitor the
traffic and locate faults promptly.
Choose the menu NetworkSwitchStatistics to load the following page.
Figure 4-14 Statistics
