Appendix A: Specifications
General
Standards
IEEE802.3 10Base-T
IEEE802.3u 100Base-TX
IEEE802.3ab 1000Base-T
Topology Star
Protocol CSMA/CD
Data Transfer Rate
Ethernet: 10Mbps (Half Duplex), 20Mbps (Full Duplex)
Fast Ethernet: 100Mbps (Half Duplex), 200Mbps (Full
Duplex)
Gigabit Ethernet: 2000Mbps (Full Duplex)
Network Media(Cable)
10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ù STP (maximum 100m)
100Base-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ù STP (maximum 100m)
1000Base-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ù STP (maximum 100m)
Number of Ports 8/16/24/48 10/100/1000Mbps Auto-Negotiation RJ45 ports
LED indicators Power, 1000Mbps Link/Act, 10/100Mbps Link/Act
Transfer Method Store-and-Forward
MAC Address Learning Automatically learning, automatically aging
Frame Filter Rate
10Base-T: 14880pps/Port
100Base-Tx: 148800pps/Port
1000Base-T: 1488000pps/Port
Frame Forward Rate
10Base-T: 14880pps/Port
100Base-Tx: 148800pps/Port
1000Base-T: 1488000pps/Port
