Configuring VLAN Overview
1
Overview
VLAN (Virtual Local Area Network) is a network technique that solves broadcasting issues
in local area networks. It is usually applied in the following occasions:

To restrict broadcast domain: VLAN technique divides a big local area network into
several VLANs, and all VLAN traffic remains within its VLAN. It reduces the influence of
broadcast traffic in Layer 2 network to the whole network.

To enhance network security: Devices from different VLANs cannot achieve Layer 2
communication, and thus users can group and isolate devices to enhance network
security.

For easier management: VLANs group devices logically instead of physically, so devices
in the same VLAN need not be located in the same place. It eases the management of
devices in the same work group but located in different places.
There are 3 types of VLAN modes supported on the switch:

MTU VLAN
MTU VLAN (Multi-Tenant Unit VLAN) defines an uplink port which will build up several
VLANs with each of the other ports. Each VLAN contains two ports, the uplink port and
one of the other ports in the switch, so the device connected to the uplink port can
communicate with the device connected to any other port, but devices connected to other
ports cannot communicate with each other.

Port Based VLAN
VLANs are divided based on ports. In port based VLAN mode, each port can only be added
to one VLAN.

802.1Q VLAN
The IEEE 802.1Q protocol defines a new format of VLAN data frame (Tagged Frame). As the
following figure shows, compared to the traditional Ethernet data frame (Untagged Frame),
the VLAN data frame (Tagged Frame) adds a VLAN tag.
On receiving a tagged frame, the switch checks the VID (VLAN ID) contained in the VLAN
tag to determine which VLAN the frame belongs to. On receiving an untagged frame, the
switch will first insert a VLAN tag to the frame, using the PVID (Port VLAN ID) of the port as
its VID, and then forward it as a tagged frame.

TP-Link TL-SG1016PE Specifications

General

Total Power over Ethernet (PoE) budget	110 W
Power over Ethernet (PoE) power per port	30 W
Power over Ethernet plus (PoE+) ports quantity	8
10G support	No
Number of VLANs	4000
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Virtual LAN features	Tagged VLAN, Port-based VLAN
Cable types supported	Cat3, Cat4, Cat5, Cat5e, Cat6
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Power connector	AC-in jack
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
Switch type	Managed
Switch layer	L2
Form factor	1U
Product color	Black
Number of fans	1 fan(s)
Housing material	Metal
Power source	AC/PoE
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	124.4 W
Jumbo frames	10000
Forwarding rate	23.8 Mpps
Number of queues	4
MAC address table	8000 entries
Packet buffer memory	4.1 MB
Maximum cable length	100 m
Compatible operating systems	Windows
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Package type	Box
Package depth	400 mm
Package width	250 mm
Package height	80 mm
Package weight	2280 g
Cables included	AC
Sustainability certificates	CE, Federal Communications Commission (FCC), RoHS

Weight and Dimensions

Depth	180 mm
Width	294 mm
Height	44 mm
