25
Chapter 3
Conguring via Web Management Interface
3. 11. Administration
3. 11. 1. LAN IP Address
Follow the steps below to configure LAN settings of the extender.
Connect to the powerline extender wirelessly. Visit http://tplinkplc.net, and log in with
the username and password you set for the extender.
Go to Device Settings > LAN Settings.
LAN Type: Select Obtain an IP address automatically to have your extender automatically
obtain IP Address from the main router. Select Use the following IP address to manually
configure the LAN parameters.
IP Address: The IP address of the powerline extender.
Subnet Mask: The subnet mask associated with IP address.
Gateway: The IP address of the gateway device.
Primary DNS: Input the DNS IP address provided by your ISP.
Secondary DNS: Input the IP address of another DNS server if your ISP provides two
DNS servers.
3. 11. 2. Set Up System Time
System time is the time displayed while the extender is running. The system time you
configure here will be used for other time-based functions like Parental Controls and
Wi-Fi Schedules. You can manually set how to get the system time.
Connect to the powerline extender wirelessly. Visit http://tplinkplc.net, and log in with
the username and password you set for the extender.
Go to Settings > Time Settings page.
