Connections
1
Digital inputs
S/P-DIF
Inputs for digital source devices with a coaxial (Cinch / RCA) digital output.
OPT
Inputs for digital source devices with optical digital output.
AES/EBU
Inputs for digital source devices with AES/EBU digital output.
BNC
Inputs for digital source devices with digital BNC output.
j
The HA 200 accepts digital stereo signals according to the S/P-DIF standard with sam-
pling rates from 32 to 192 kHz at all inputs.
2
Analog inputs
IN 1
Universal line input for connecting any stereo audio device or TV set with unbalanced
RCA output.
IN 2
Universal line input for connecting any stereo audio device with balanced XLR output.
3
Bluetooth
BT ANT
Connection for the Bluetooth antenna.
4
USB inputs
USB IN
Connection socket for a PC or MAC computer.
The HA 200 accepts digital PCM stereo signals with sampling rates of 44.1...768 kSps
and digital DSD stereo signals from DSD64 to DSD1024* at this input.
* DSD512 to DSD1024 only from a Windows PC.
USB SYS
USB interface for possible future extensions.
This and the following chapter
describe all things of funda-
mental importance for instal-
lation and setup that are not
relevant for the daily use of the
device, but which should be
read and observed before the
rst use.
40
