TQC AB6000 - 10.4.4 Abrasive Pad Tool (AB5013)

25 |
The Abrasive Pad Holder is supplied ready for
use. The pad is used to test scrub resistance of
coatings. The pads cause an aggressive wear of
the coating.
Placement
The AB5013 Abrasive Pad Tool is placed in the
AB5042 or AB5041 holder and needs to fit
comfortably in the holder. The tool must be able
to move freely without friction in the holder.
Always position the tool facing the same way,
to create the best homogeneity in results. For
replacement intervals and maximum life please
check the appropriate standard.
Scope of supply
• Abrasive pad
• Pad holder
• Fixation screw
Specications Abrasive Tool Complete
Mass: 135 g / 4.76 oz
Specications Aluminium Pad Holder
Material: Aluminium
Inner dimensions: 92x41 mm
Outer dimensions: 94x43 mm
Scope of supply
• Clamp tool upper part with fixation screw
• Clamp tool lower part with rubber lining on the
bottom and a separate rubber lining for both
short sides
Specications
Universal Material Clamp Tool. Assembly of two black
anodised aluminum blocks with rubber lining into which
user-selected abrasive material can be clamped.
Dimensions: 75x40x80 mm
(without rubber lining on
the short sides)
Scope of supply
• TQC MEK / Crockmeter tool
• Weight
• Set of felts and Viton O-rings
Specications
Required Mass: 454 g
Standard Delivery: 200g
Order extra (not included): + 1x AB5065 (54 g)
+ 2x AB5015 (100g)
Required Mass: 900g
Standard Delivery: 200g
Order extra (not included): + 1x AB5015 (100g)
+ 3x AB5066 (200g)
The Universal Material Clamp Tool is designed to
hold abrasive media as sandpaper, cloth, towel
material, etc. The rubber lining on the bottom
create a uniform pressure on the bottom. The
rubber pads on each side allow for the size
adjustment to any thickness of cloth.
Placement
The AB5020 Universal Material Clamp Tool is
placed in the AB5042 or AB5041 holder and
needs to fit comfortably in the holder. The tool
must be able to move freely without friction in
the holder. Always position the tool facing the
same way, to create the best homogeneity in
results. For replacement intervals and maximum
life please check the appropriate standard.
The AB5060 MEK / Crockmeter is designed to
perform several types of MEK / Crockmeter tests,
depending on the configuration used. A full set
weighs 200g. The hollow fixation screw allows for
easy filling of the liquid reservoir in the stamp.
Placement
The AB5060 MEK / Crockmeter tool is placed in
the AB5042 or AB5041 holder and needs to fit
comfortably in the holder. The tool must be able
to move freely without friction in the holder.
Always position the tool facing the same way,
to create the best homogeneity in results. For
replacement intervals and maximum life please
check the appropriate standard.
10.4.4 Abrasive Pad Tool (AB5013)
10.4.5 Universal Material Clamp (AB5020)
10.4.6 MEK / Crockmeter Tool (AB5060)
